Single Loop Detector

11-loop-detector---dispenser--www_delapanbintanggate_com-by-nirwana-group



Spesifikasi Loop Detector :

  • Supply voltage AC: 220V, 110V, 24V, 12V
  • Supply voltage DC: 24V, 12V
  • Sensitivity: adjustable in 3 increments (high. medium. low)
  • Operating temperature: -20 to +65º C
  • Storage temperature: -40 to +85º C
  • Frequency range: 20 KHz to 170 KHz
  • Reaction time: 100ms
  • Loop inductance: Ideal: 80μH to 300μH
  • (incl. conn. wiring): max: 50μH to500μH
  • Loop connection: <5m optimal
  • Loop connection wiring: Maximum length 200 meters,
  • Twisted at least 20 times per meter
  • Dimensions: 35x74x85 mm (WxHxL)
  • Net Weight: 300g



Vehicle Loop Detector

Vehicle Loop Detector

Spesifikasi :

  • Suplai tegangan : 220V AC
  • ToleransiTeganganAC : + 10 % / -15 %
  • Konsumsi Daya : 4.5VA
  • Keluaran relay : 240V / 5A
  • Suhu operasi : -20 ° C sampai 65 &deg ; C
  • Suhu penyimpanan : -40 ° C sampai 85 &deg ; C
  • Rentang frekuensi : 20 kHz sampai 170 kHz
  • Waktu reaksi : 10 ms
  • Sinyal holding time :Terbatas / terbatasketika loop secarapermanentertutup 10 menit
  • Sensitivitas : Adjustable di 4 bertahap
  • Lingkaran induktansi : Total lingkaranditambahkoneksikabel : 50 & mu ; H 1000 & mu ; H .
  • Ideal adalah 100 &mu ; H 300 & mu ; H
  • Koneksi lingkaran kabel : Maksimum panjang 20 meter , memutar setidaknya 20 kali per meter
  • Ukuran Perumahan : 78x40x108 mm ( L x W x H )
